| Brand Name: | APEEK |
| Model Number: | PEEK 1000 |
| MOQ: | 1KG |
| Price: | Negotiable |
| Supply Ability: | 250Tone per month |
Heat Temperature Resistance Continous Extrusion Plastic PEEK Sheet
PEEK Descriptions:
PEEK is a semi-crystalline,show high stiffness and hardness. and an unique high tensile strength and fatiue strength,Resistant to high-engery radiation.High abrasion and wear resistant.Good electrical insulator even at high voltages,and is characterised mainly by its very good mechanical properties and exceptional dimensional stability even continous operation at high temperatures of up to 250°C..
Features And Benefits Virgin Peek Sheet
Chemical resistant, hydrolysis resistant, autoclavable.
Easy to machine and fabricate.
Good mechanical properties at elevated temperatures.
Strong and stiff.
UL 94 V-0 flammability rating(0.059" thickness).
Very low smoke and toxic gas emissions when exposed to flame.
PEEK RESIN SHEET SPECIFICATION
| Thickness*Width*Length Dimension(MM) |
Weight(KG) | Thickness*Width*Length Dimension(MM) |
Weight(KG) |
| 1x610x1220 | 1.100 | 25x610x1220 | 26.330 |
| 2x610x1220 | 2.110 | 30x610x1220 | 31.900 |
| 3x610x1220 | 3.720 | 35x610x1220 | 38.480 |
| 4x610x1220 | 5.030 | 40x610x1220 | 41.500 |
| 5x610x1220 | 5.068 | 45x610x1220 | 46.230 |
| 6x610x1220 | 6.654 | 50x610x1220 | 53.350 |
| 8x610x1220 | 8.620 | 60x610x1220 | 62.300 |
| 10x610x1220 | 10.850 | 100x610x1220 | 102.500 |
| 12x610x1220 | 12.550 | 120x610x1220 | 122.600 |
| 15x610x1220 | 15.850 | 150x610x1220 | 152.710 |
| 20x610x1220 | 21.725 | 160x610x1220 | 160.900 |
Application of Peek Sheet
● Analytical Instruments Industry
● Food Processing and Filling Machinery Industry
● Electronics Semiconductor Industry
● Medical Device Industry
● Automotive Industry
● Petrochemical Machinery Industry
● Textile Machinery Industry
● Aerospace, Military Industryratio
