| Brand Name: | APEEK |
| Model Number: | PEEK 1000 |
| MOQ: | 100pcs |
| Price: | 2-3 |
| Payment Terms: | D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000 piece per month |
Wear resistant Peek fiber optic connector
Wear resistant PEEK fiber optic connector is a high-performance connecting component. It is made of polyetheretherketone (PEEK) material, which has excellent wear resistance and can withstand frequent insertion and long-term use. This type of connector can effectively reduce signal transmission problems caused by wear and tear while maintaining high-precision connections, ensuring stable transmission of optical signals. It has high mechanical strength and can adapt to various complex usage environments. Compared with optical fiber connectors made of other materials, PEEK optical fiber connectors also have good chemical stability and aging resistance, long service life, and are widely used in communication, data center and other fields requiring high connection reliability.
| PEEK Parameters | |||||
| NO. | Item no. | Unit | PEEK-1000 | PEEK-CA30 | PEEK-GF30 |
| 1 | Density | g/cm3 | 1.31 | 1.41 | 1.51 |
| 2 | Water absorption (23℃ in air) |
% | 0.2 | 0.14 | 0.14 |
| 3 | Tensile strength | MPa | 110 | 130 | 90 |
| 4 | Tensile strain at break | % | 20 | 5 | 5 |
| 5 | Compressive stress(at 2% nominal strain) | MPa | 57 | 97 | 81 |
| 6 | Charov impact strength(unnotched) | KJ/m2 | No break | 35 | 35 |
| 7 | Charov impact strength(notched) | KJ/m2 | 3.5 | 4 | 4 |
| 8 | Tensile modulus of elasticity | MPa | 4400 | 7700 | 6300 |
| 9 | Ball indentation hardness | N/mm2 | 230 | 325 | 270 |
| 10 | Rockwell hardness | -- | M105 | M102 | M99 |
